Production Capacity: | 100 | Warranty: | 1 Year |
---|---|---|---|
Dimension(l*w*h): | 660*510*1350 Mm | Power(w): | 9/18 KW |
Voltage: | 380V | Weight (kg): | 88 |
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Core Components: | Motor, Engine, Pump | Power Supply Power: | 9/18 KW |
Work Pressure: | 0.45 Mpa | Water Capacity: | 27 L |
Evaporation Amount: | 25 KG/H |
Product Specifications | Unit | LDR6-0.45-Z | LDR9-0.45-Z | LDR12-0.45-Z | LDR18-0.45-Z | |||
Power supply power | KW | 2/4/6 | 3/6/9 | 6/12 | 9/18 | |||
Operating voltage | V | 220 | 220/380 | 380 | 380 | |||
Work pressure | Mpa | 0.45 | ||||||
Water capacity | L | 27 | ||||||
Evaporation capacity | Kg/h | 8 | 12 | 16 | 25 | |||
weight | KG | 85 | 85 | 85 | 88 | |||
size | mm | 660*510*1220 | 660*510*1220 | 660*510*1220 | 660*510*1350 |
