The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech

The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech

The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech

Large Image :  The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech

Product Details:
Place of Origin: Shanghai, China
Brand Name: AoZhi
Detailed Product Description
Production Capacity: 100 Warranty: 1 Year
Dimension(l*w*h): 805*850*1420 Mm Power(w): 1.5
Voltage: 220V, 380V, 110V Weight (kg): 300
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Core Components: Engine, Motor Washing Machine: 12 Kg
Drum Diameter: 650 Mm Washing Speed: 40 RPM/min
Power Supply Voltage: AC110/220/380 415/440/50-60Hz V Cold/hot Water Pipe Diameter: 3/4 Inch

Product Description

Product Application
1. We are professional leading original equipment manufacturer in China. Our products are not only elegant, but also durable and our price is very competitive.
2. The model, size, color and other details of our products can be customized. You can tell us your requirements and we will give you some advice and try our best to satisfy your needs.
3. If you want to cooperate with us, you can pay field visit to our factory and we can provide you with free training. True gold does not fear fire.
4. We can provide you with some free parts with our products. When our product breaks down during normal operation under warranty period, we can deliver some parts to you for free and send you videos to teach you how to repair it.


XQG-12
XQG-15
XQG-20
XQG-25
Washing Capacity
12 kg
15 kg
20 kg
25 kg
Drum Diameter
650mm
650mm
750mm
800mm
Drum Depth
360mm
450mm
455mm
500mm
Door Diameter
560mm
410mm
410mm
Washing Speed
40 r/min
1.5 KW
1.5 KW
2.2 KW
Medium dehydration speed
500r/min
480 r/min
450 r/min
430 r/min
High dehydration speed
900 r/min
850 r/min
800 r/min
800 r/min
Cold/hot water pipe diameter
3/4 inch
DN80
DN80
DN80
Drain pipe diameter
3/4 inch
850*950*1500 mm
880*1000*1500 mm
880*1100*1500 mm
W*D*H
805*850*1420 mm
805*950*1420 mm
805*1080*1370 mm
910*1085*1400 mm
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 0

Main Features

Commercial self-service washing machines are emerging washing equipment, such as hotel laundry, school laundry, hospital washing machinery, washing centers, foot massage sauna centers, dry cleaners and other places. They use coin
operated, card swiping, WeChat payment, Alipay payment and other payment methods. Efficient and fast washing mode is an element to attract the young generation.
★ Adopting hard connection fixation to ensure stable operation of the machine. Customized coin insertion function;


★ Large drum design, using high-quality stainless steel material to avoid damaging clothing;
★ The washing, uniform distribution, and dehydration speed can be optimized according to actual needs;
★ Built in washing box design to avoid direct contact with clothes;
★ The clothing door is equipped with a safety door lock and a control linkage device to protect the safety of operators, suitable for hotels, laundry rooms, schools, etc.

Certifications
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 2
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 4
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 6
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 8
Our Service
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 10

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 12

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
The Smarter Way to Wash -Fixed Type XQG Self-Service Machines with Advanced Payment Tech 14
Packaging
Size
905(W) * 950 (D) * 1520 (H) mm
Weight
350 kg



Packaging Details
Syntheic board
Wood pallet
