Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments

Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments

Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments

Large Image :  Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments

Product Details:
Place of Origin: Shanghai, China
Brand Name: AoZhi
Detailed Product Description
Production Capacity: 100 Warranty: 1 Year
Dimension(l*w*h): 1750*1200*2150 Power(w): 2.2
Voltage: 380V, 220V Weight (kg): 900
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Core Components: Motor, Engine Washing Capacity: 12 Kg
Drum Volume: 220 L Drum Size: 800*400 Mm
Running Speed: 30-600 Rpm/min Liquid Pump Power: 0.55 KW
Fan Power: 0.75 KW Drying Power (electricity): 5.4 KW
Distillation Power (electricity): 6 KW Steam Pressure: 0.4 Mpa
Compressed Air Pressure: 0.4-0.6 Mpa

Product Description

Product Application
1. We are professional leading original equipment manufacturer in China. Our products are not only elegant, but also durable and our price is very competitive.
2. The model, size, color and other details of our products can be customized. You can tell us your requirements and we will give you some advice and try our best to satisfy your needs.
3. If you want to cooperate with us, you can pay field visit to our factory and we can provide you with free training. True gold does not fear fire.
4. We can provide you with some free parts with our products. When our product breaks down during normal operation under warranty period, we can deliver some parts to you for free and send you videos to teach you how to repair it.


GXZQ-10
GXZQ-12
GXZQ-16
GXZQ-20
washing Capacity
10 kg
12 kg
16 kg
20 kg
drum volume
185 L
220 L
320 L
415 L
Drum Size
800*365 ¢mm
800*440 ¢mm
900*500¢mm
980*550 ¢mm
running speed
30-600 Rpm/min
0.75*2 KW
1.1*2 KW
1.1+1.5 KW
rated voltage
380/220 V
380/220 V
380 V
380 V
motor power
2.2 KW
2.2 KW
3.6 KW
3.6 KW
Liquid pump power
0.55 KW
7.5KW
fan power
0.75 KW
35 H/kg
50 H/kg
70 H/kg
Drying power (electricity)
5.4 KW
5.4 KW
/
/
Distillation power (electricity)
6 KW
6 KW
/
/
steam pressure
0.4 Mpa
400 kg
450 kg
550 kg
compressed air pressure
0.4-0.6 Mpa
size
1700*1200*2150mm
1750*1200*2150 mm
1800*1310*2150 mm
1850*1360*2150 mm
weight
850 kg
900 kg
1000 kg
1300 kg
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 0

Main Features

Using highly extractable tetrachloroethylene as a solvent to effectively decompose stains in clothing! Recommended laundry equipment for hotel laundry rooms, dry cleaners, and more!
★ PLC operating system, optional automatic/manual control, real-time monitoring and viewing of washing process;
★ Closed washing and drying, in compliance with environmental requirements for emissions;
★ Leak proof chassis, more in line with European standards; Drying can choose electric heating/steam heating;
★ Low temperature washing, refrigeration recovery, lower energy consumption;

★ Fully galvanized treatment and internal stainless steel structure effectively extend the service life of the machine; Complete galvanizing treatment and internal stainless steel structure can effectively extend the service life of the machine;

Certifications
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 2
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 4
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 6
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 8
Our Service
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 10

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 12

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Commercial Energy-Efficient Dry Cleaning Machine Closed System with High Extraction PLC Touch Screen Washing Equipments 14
Packaging
Size
1850 (L) * 1300 (W) * 2250 (H) mm
Weight
950kg



Packaging Details
Syntheic board
Wood pallet
