Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions

Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions

Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions

Large Image :  Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions

Product Details:
Place of Origin: Shanghai, China
Brand Name: Aozhi
Detailed Product Description
Production Capacity: 100 Warranty: 1 Year
Dimension(l*w*h): 1110*1150*1570mm Power(w): 2.2KW
Voltage: AC110/220/380/415/440/50-60Hz Weight (kg): 700
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Washing Capacity: 18-22kg Drum Volume: 220L
Drum Size: 750*500mm Washing Speed: 32-800Rpm/min
Cold/Hot Water Pipe Diameter: 20DN Drainage Pipe Diameter: 50DN
Voice: >70dB Used For: Hotel, College, Laundry Shop, Hospital

Product Description

Product Application
1. We are professional leading original equipment manufacturer in China. Our products are not only elegant, but also durable and our price is very competitive.
2. The model, size, color and other details of our products can be customized. You can tell us your requirements and we will give you some advice and try our best to satisfy your needs.
3. If you want to cooperate with us, you can pay field visit to our factory and we can provide you with free training. True gold does not fear fire.
4. We can provide you with some free parts with our products. When our product breaks down during normal operation under warranty period, we can deliver some parts to you for free and send you videos to teach you how to repair it.


XGQ-15
XGQ-20
XGQ-25
XGQ-30
Washing Capacity
13-16kg
18-22kg
23-25kg
25-30kg
Drum volume
155L
220L
250L
280L
Drum size
630*500mm
750*500mm
800*500mm
800*600mm
Speed
32-800RPM/min
32-800RPM/min
32-800RPM/min
32-800RPM/min
Power supply voltage
AC110/220/380/415/440/50-60Hz
Motor power
1.5kw
2.2kw
2.5kw
3kw
Inverter power
1.5kw
2.2kw
3kw
4kw
Electric heating power
6kw
6/9kw
Cold/Hot water pipe diameter
DN20
Drainage pipe diameter
DN50
Voice
>70
Size
1000*1100*1500mm
1110*1150*1570mm
1160*1150*1570mm
1300*1250*1700mm
Weight
600kg
700kg
750kg
800kg
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 0
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 2
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 4
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 6

Main Features

Washing machine is an ideal equipment for washing cotton, wool, linen, chemical fiber and other clothing and fabrics in hotels, restaurants, guesthouses, washing and dyeing industries, universities and other enterprises and institutions. It has the advantages of good washing, low noise and vibration, beautiful appearance, and innovative structural design.
1、PLC operating system, automatic control/manual control is available for our choice, and the washing process can be monitored and viewed in real time.;
2、Using variable frequency high-speed motor drive to achieve stepless speed change and reduce vibration;
3、Adopting a sports suspension design, it has spring buffering and damping shock absorption functions during movement;
4、The soft installation structure eliminates the need for foundation fixation;
5、Multiple language operating systems are available (English, French, Spanish, Russian, Korean, Japanese, etc).


Certifications
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 8
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 10
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 12
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 14
Detailed Images
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 16

FREE STANDING HIGH SPEED

The machine is designed for 300 G-force high extract accepted by most laundry worldwide remove more moisture than other low or medium spin machines after extract, reducing the time and energy for drying or ironing while protecting the fabrics.

FREQUENCY INVERTER DRIVE

Frequency inverter drive allows programmable variable wash speed to suits wide variety of fabrics.

Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 18
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 20

PERFECT CLEANING QUALITY

Large diameter basket with multiple ribs produces better mechanical wash action for optimum wash quality with less detergent. Single motor inverter drive allows programmable right wash speed for wide variety of fabrics. 2 automatic detergent cups turn over and flush all detergents thoroughly into the basket, no remaining lump in cups.

 ROBUST INDUSTRIAL STRENGTH

The robust long lasting structural proven by Finite Element Analysis is supported by 4 industrial strength springs and multiple shock absorbers provide excellent suspension minimize the wasted time and energy due to unbalance during daily operation.

Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 22
Our Service
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 24

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 26

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Smart Touch Panel Industrial Laundry Washer with Anti-Vibration Design Customized Washing Equipment Solutions 28
Packaging
Size
1210 (W) * 1250 (D) * 1670 (H)
Weight
750kg



Packaging Details
Syntheic board
Wood pallet
